1,Touch screen parameters

Touch screen type

Projected capacity touch screen

Response time

5ms

Touch points

Standard 10-point touch

Touch recognition

1.5mm(Finger, touch pen opaque objects)

Scanning rate

200 Hz

Scanning accuracy

4096×4096

Communication

Full-Speed USB 2.0,3.0

Theory Clicks

More than 50 million times

Operating current / voltage

180Ma/DC+5V±5%

Anti-light interference

Sunlight, incandescent, fluorescent and other light during normal use change

Touch data output

Coordinate output

Surface hardness

Physical steel Mohs 7 explosion-proof glass

Operating System Compatibility

Windows 7/ Windows 8 / Windows XP / Linux /MAC OS /Android

Drive

Free drive, plug and play

2,LED screen parameters

Screen Type

LED backlight, A-type

Resolution

1920*1080P

Brightness

250 cd

Contrast ratio

5000:1

Response time

5.5ms

Number of colors

16.7M(8-bit 2(LVDS) Channel low-voltage differential signal)

Refresh rate

60Hz

Viewing angle

178 degrees horizontal,178 degrees vertical

Life time

50000 hours

3,Display parameters (as a touch display only partially used)

Power Interface

12V

VGA input(15-pin D-Sub)

1

High-definition multimedia interface(HDMI)

1

DVI Interface

1

PC-AUDIO input

1

Headphone output

1

Sound output power

2*10W

Number of Loudspeakers

2

4,Power supply parameters

Input Power

110-240V AC 50/60Hz

Overall power consumption

100W or 120-140W

Standby power consumption

3W

5,Working environment

Operating temperature

0℃-38℃

Working humidity

10% - 95%

Storage temperature

0℃-40℃

Storage humidity

10% - 95%

6,Standard Accessories

Instructions

Electronic file specification

Power Adapter

1 pc

Wall mount

1 set

Warranty Card

1 set

Certificate

1 set
